hydraulic well drilling rig is hydraulic drilling equipment for rural water supply, agricultural irrigation, geothermal and engineering dewatering projects. The listed 0-150m drilling depth, 80-300mm borehole range, 950kg give contractors and distributors a practical starting point for jobsite and transport planning.
Hydraulic Well Drilling Rig for Water-Well Projects
This hydraulic well drilling rig combines hydraulic functions with the walking style, power-head, feed system and drill-rod information shown in the verified product data below. Buyers should match formation conditions, target depth, bore diameter and drill tooling before ordering.
Compare related Tuojie water well drilling rigs or contact Tuojie Machinery to confirm configuration, drill bits, packing, shipping and B2B quotation details.
Hydraulic Well Drilling Rig Features and Technical Data
| Advantages |
Basic Parameters |
Unit |
Factory |
Packaging Volume (CBM) |
Packaging Weight (KG) |
Packaging Size (MM) |
- 1. The diesel engine is equipped with electric start for easy operation, reducing the operator’s labor intensity.
- 2. The drilling rig adopts hydraulic working principle and is equipped with a radiator, enabling continuous and efficient operation.
- 3. Equipped with high-power hydraulic motor, the power head can rotate forward and reverse.
- 4. The drill stand is equipped with a hydraulic cylinder, which can be lifted and lowered by operating the handle.
- 5. The drilling rig has a built-in water pump with reasonable structure, compact layout and good slag discharge effect.
- 6. The crawler version is equipped with rubber steel wire crawler belts, which is convenient to move and will not damage the road surface when walking on urban roads.
- 7. The overall structure of the drilling rig is compact and stable, which can effectively maintain stable drilling during the drilling process.
|
- + Walking style: Tire traction type
- + Total machine power: Single-cylinder diesel engine / 22 horsepower
- + Total vehicle weight: 950kg
- + Overall dimensions: 2000*1150*2100mm
- + Power head: BM5-200 Hydraulic Motor
- + Compression system: Hydraulic Cylinder with Force Addition Type
- + Leg support: 4 hydraulic legs
- + Rod size specification: 50*1500mm
- + borehole diameter: 80-300mm
- + drilling depth: 0-150m
- + travel of slide rail: 2400mm
- + Rise height: 2600mm
- + One-time push-through length: 1500mm
|
set |
Huihao |
6 |
1100 |
2150*1150*2100 |
| Function Introduction |
Standard Product Features |
Upgrade Configuration |
Drill Bit Selection |
Standard Colors |
Work Scenario |
| Full hydraulic drive, infinitely variable speed with high-torque motor for efficient drilling; Electric start diesel engine with dedicated heat dissipation system for stable operation in high-temperature environments; Built-in water pump for positive circulation slag discharge; Wheel / crawler multi-mode walking for all-scenario construction; Compact structure, common accessories for easy maintenance. |
- 22 HP Changzhou single-cylinder water-cooled engine;
- Diesel engine accessories (start battery + electric start motor + fuel tank + air filter + cooling water tank);
- High-torque hydraulic power head;
- Hydraulic cylinder;
- Hydraulic gear oil pump;
- Multi-way directional control valve group;
- Hydraulic accessories (high-pressure oil pipe + joints + filter + pressure gauge);
- Main body welded frame + traction frame;
- Grille-type power protection cabin;
- Sliding frame assembly (guide rail + lifting power head bracket);
- Rubber crawler walking chassis;
- Hydraulic outriggers;
- Electrical assembly (electric door lock + start switch + wiring harness + insurance);
- Control handle + console parts.
|
- 25 HP Changzhou single-cylinder water-cooled diesel engine;
- 28 HP Changzhou single-cylinder water-cooled diesel engine;
- 32 HP Changzhou single-cylinder water-cooled diesel engine;
- 35 HP Changzhou single-cylinder water-cooled diesel engine;
- 25 HP RunTong Euro V two-cylinder air-cooled diesel engine;
- 25 HP EPA RunTong Euro V two-cylinder air-cooled gasoline engine;
- 35 HP EPA RunTong Euro V two-cylinder air-cooled diesel engine;
|
- Drill pipe: Φ50mm/L1.5/6.5kg/pc
- Three-wing alloy drag bit: Φ8~35cm
- PDC non-core composite bit: Φ6/8/10/13/15/20/25/30/35cm
|
Black/Yellow |
- Africa & Middle East: Rural drinking water wells and drought-resistant irrigation wells. In Africa and the Middle East, hydraulic water well drilling rigs are mainly used for rural drinking water wells and drought-resistant irrigation wells. These water wells are crucial for meeting domestic water and agricultural irrigation needs in areas with relatively scarce water resources.
- Southeast Asia: Agricultural irrigation, geothermal heat pumps, engineering dewatering. Southeast Asia has a humid climate and developed agriculture, where hydraulic water well drilling rigs can be used for agricultural irrigation. Meanwhile, there is also demand in geothermal heat pumps and engineering dewatering fields to support local agricultural and engineering construction.
- South America: Mine auxiliary water, ranch water wells. South America has many mines and ranches, where hydraulic water well drilling rigs can provide auxiliary water for mines to meet the water demand during mine production. They can also drill water wells for ranches to ensure drinking water supply for livestock.
- Eastern Europe & Central Asia: Domestic water wells, ground pipe heat exchange holes. In Eastern Europe and Central Asia, residents have a demand for domestic water wells to solve daily domestic water problems. In addition, hydraulic water well drilling rigs are also used in the construction of ground pipe heat exchange holes for geothermal heat pump systems.
|
Typical Drilling Applications
- Rural drinking-water and agricultural irrigation wells
- Geothermal and ground-source heat-pump projects
- Engineering dewatering and ranch water supply
- Contractor and distributor equipment fleets
Hydraulic Well Drilling Rig FAQ
What formations can this rig drill?
Formation capability depends on the selected bit, hydraulic configuration and ground conditions. Match the drill tooling to clay, sand, gravel or weathered formations with technical guidance before work begins.
Which specifications should buyers confirm?
Confirm target depth, bore diameter, drill-rod size, power configuration, walking style, machine weight and shipping dimensions for the planned project.
Can Tuojie supply drill bits and export support?
Yes. Buyers can request compatible drill tooling, machine configuration, packing, shipping and quotation details from Tuojie Machinery.
